Application description: The black light guide fiber is a light guide material. It is composed of a transparent fluoropoly compound core + black PVC. It does not emit light or is connected to a power source. It needs to be illuminated by LED light to show any color of light. Using the principle of total emission of light, the light energy is transmitted from one end of the optical fiber to the other end, forming an end-light effect. | ||||||||
| 序号 | 型号 | 名称 | 尺寸（MM) | 重量 （KG/M) | 材料 | 纤芯 折射率 | 温度范围 （℃） | 盘长（M /卷） |
| 1 | SOK-1 | 黑皮光纤 | Ф1.0*2.2 | 0.004 | PMMA+PE | 1.49 | -50~+70 | 1500 |
| 2 | SOK-1.5 | 黑皮光纤 | Ф.1.5*2.5 | 0.008 | PMMA+PE | 1.49 | -50~+70 | 700 |
| 3 | SOK-2 | 黑皮光纤 | Ф2*3 | 0.01 | MMA+PVC | 1.55 | -50~+70 | 100 |
| 4 | SOK-2.5 | 黑皮光纤 | Ф2.5*3.5 | 0.016 | MMA+PVC | 1.55 | -50~+70 | 100 |
| 5 | SOK-3 | 黑皮光纤 | Ф3*4.5 | 0.025 | MMA+PVC | 1.55 | -50+70 | 100 |
| 6 | SOK-4 | 黑皮光纤 | Ф4*5.5 | 0.04 | MMA+PVC | 1.55 | -50~+70 | 100 |
| 7 | SOK-5 | 黑皮光纤 | Ф5*6.3 | 0.065 | MMA+PVC | 1.55 | -50~+70 | 100 |
| 8 | SOK-6 | 黑皮光纤 | Ф6*7.5 | 0.085 | MMA+PVC | 1.55 | -50~+70 | 100 |
| 9 | SOK-8 | 黑皮光纤 | Ф8*11 | 0.15 | MMA+PVC | 1.55 | -50~+70 | 100 |
| 10 | SOK-10 | 黑皮光纤 | Ф10*13 | 0.2 | MMA+PVC | 1.55 | -50~+70 | 100 |
| 11 | SOK-12 | 黑皮光纤 | Ф12*14 | 0.25 | MMA+PVC | 1.55 | -50~+70 | 100 |
| 12 | SOK-14 | 黑皮光纤 | Ф14*17.3 | 0.3 | MMA+PVC | 1.55 | -50~+70 | 100 |
| 13 | SOK-16 | 黑皮光纤 | Ф16*18 | 0.35 | MMA+PVC | 1.55 | -50~+70 | 100 |
The black light guide fiber is a light guide material. It is composed of a transparent fluoropoly compound core + black PVC. It does not emit light or is connected to a power source. It needs to be illuminated by LED light to show any color of light. Using the principle of total emission of light, the light energy is transmitted from one end of the optical fiber to the other end, forming an end-light effect.
POF Plastic Optical Fiber Cable PMMA Fiber Optic
