Mitsubishi fiber optical cable SH-Consumer Data SH3001 SH4001 SH4001-1.3 SH4002

As early as the 1970s, Mitsubishi developed a plastic optical fiber with PPMA and polystyrene as the core material and a low refractive index fluoroplastic as the cladding. Since then, it has continued to develop. At present, its plastic optical fiber has developed multiple levels The product.

Optical fiber cable formed by bare fiber through coating process. You can choose SUPER ESKA, ESKA PREMIER, ESKA MEGA series according to the actual use.

GH-grade credit. It is widely used in automotive network connection and industrial control applications. Can optimize the characteristics of the machine. Heat-resistant temperature of 85 degrees.

SH level standard level. It is used as people's livelihood data communication, sensor. 70 ° C

Low-grade fiber that is widely used for SH-grade sensing and communication applications. Common models are single-core SH-1001-1.0, SH-2001-J, SH-4001

SH-4001-1.3, SH-6001, dual-core has SH-4002, multi-core specifications are 0.265mm core series SH-1004-N, SH-1009-1.25, SH-1016,

SH-1032, SH-1064

High performance Mitsubishi fiber optical cable SH-Consumer Data SH3001 SH4001 SH4001-1.3 SH4002

Application scope of communication plastic optical fiber:

For fiber-to-the-home (FTTH)

Cooperating with quartz fiber, it is effective at the end of the broadband network. Plastic fiber is a good solution to solve the problem of "the last few hundred meters".

For consumer electronics

Plastic optical fiber is used in navigation equipment, in-car communication and on-board entertainment audio-visual systems, in-car TVs, DVD players, stereos, lamps, and digital switch sensor connection lines.

For automotive intelligence SH3001 SH4001 SH4001-1.3 SH4002

For industrial control and monitoring systems

SH4001 Mitsubishi fiber optical cable
